Table of Contents
1. Product Overview
2. Working Principle
3. Daily Application Scenarios
4. Comparison with Traditional Sanitation Vehicles
5. Buying Guide
6. Operation and Maintenance Tips
7. Frequently Asked Questions
Conclusion
1. Product Overview
Core Product Keywords: SHACMAN L3000 4×2 Sprinkler Truck, Multi-functional
Water Spray Truck, Road Dust Suppression Vehicle, Landscape Watering Truck, Municipal Sanitation
Water Tank Truck, LHD & RHD Sanitation Truck.
The sprinkler truck, also referred to as spray truck, multi-functional sprinkler vehicle, landscape watering truck, water tank truck and water transport truck, is a versatile sanitation vehicle for environmental maintenance and construction operations.
Standard Configuration
This vehicle is fully equipped with standard functional components including front flushing nozzles, rear sprinkling nozzles and side sprayers. A rear working platform is installed and fitted with a high-pressure water cannon featuring 360° full rotation and adjustable spray modes, including straight jet, heavy rain, moderate rain, light rain and drizzle. The straight jet mode delivers a maximum shooting range of no less than 35 meters, while the mist spray mode achieves a maximum range of no less than 15 meters.
It is configured with a high-performance high-power dedicated sprinkler pump and brand-name power take-off (PTO), matched with a debris filter to ensure clean water circulation. Equipped with a universal DN65 fire coupling, the vehicle supports fast water replenishment via fire hydrants. Additionally, it is fitted with a self-priming and self-discharging ball valve system with a maximum suction lift of 7 meters, together with two steel wire reinforced rubber water hoses for water diversion.
Core Advantages
Yonghang designed and produced Shaanxi L3000 heavy-duty 4×2 left-hand & right-hand drive
Water Sprinkler Truck is built based on L3000 heavy-duty truck chassis, equipped with 210HP Weichai WP6.210E32 diesel engine (Euro II emission standard), matched with 8-speed Fast manual transmission, Hande front and rear axles, multi-leaf spring suspension, hydraulic main seat, water tank protection gear and 1 warning light on the tank’s top for reliable heavy-load performance. It is fitted with a large-capacity water tank upper assembly, paired with hydraulic control valves for water cannon and spraying mechanisms, which ensures safe, stable and convenient daily operation. This model is widely sold and applicable to countries across Southeast Asia, Africa, Central America, South America, the five Central Asian states and the Middle East.
2. Working Principle
The complete working system of SHACMAN L3000 4×2 sprinkler truck consists of three core parts: original SHACMAN L3000 chassis power system, dedicated water supply system and multi-functional spraying execution system.
After the vehicle engine starts, the power take-off obtains power from the chassis engine to drive the dedicated sprinkler pump to operate stably. The truck can finish rapid water intake through external water sources, fire hydrants or self-priming pipelines; the built-in debris filter blocks sediment and impurities to prevent pipeline and pump body clogging and guarantee smooth water circulation.
Operators control hydraulic valves to switch spraying modes freely. Water flows to front flushing nozzles, side sprayers and rear high-pressure water cannon respectively to realize road flushing, dust suppression, watering and fire spraying. With adjustable water output and 360° rotatable water cannon, it realizes multi-scene flexible operation. The whole spraying and water-absorbing process adopts full-mechanical linkage, featuring easy operation and low energy consumption.
3. Daily Application Scenarios
Urban Sanitation Maintenance: Daily road surface flushing, urban road dust suppression, street cleaning and cooling
Landscape Greening Irrigation: Irrigation and maintenance of urban trees, green belts, community lawns and scenic vegetation
Construction & Mining Operation: Dust reduction for highway construction, factory and mine site cleaning, construction site sediment flushing
Special Emergency Work: High-rise building exterior cleaning, daily urban fire emergency rescue and fire water supply
Public Environmental Treatment: Pesticide spraying for urban pest prevention, urban heat island mitigation, road surface humidification
4. Comparison with Traditional Sanitation Vehicles
Vs Manual Watering Equipment: Traditional manual water carts and water pipes require massive labor work, limited spraying range and low working efficiency, unable to cover wide urban roads. This
SHACMAN Sprinkler Truck realizes automatic water suction and spraying, covering long-distance operation, greatly cutting manpower cost.
Vs Ordinary Simple Water Tank Trucks: Common water tank trucks only support single water transportation, without multi-angle spraying function and high-pressure water cannon, lacking fire rescue and high-altitude watering capacity. This L3000 model integrates 6-in-1 functions, meeting diversified sanitation demands.
Vs Single-function Sprinkler Trucks: Ordinary small sprinkler trucks adopt low-power engine, narrow spraying range and poor road adaptability, only supporting simple watering. SHACMAN L3000 equips heavy-duty chassis and Weichai power engine, supports LHD & RHD customization, adapting to overseas complicated road conditions and cross-border traffic rules.
5. Buying Guide
For overseas municipal sanitation departments, engineering contractors and sanitation fleet purchasers, please verify key configurations before bulk procurement:
Genuine SHACMAN L3000 4×2 Chassis: Reliable heavy-duty sanitation chassis, matched with 210HP Weichai diesel engine and Fast transmission, mature powertrain, durable frame, supporting LHD and RHD customized production to fit global traffic regulations.
Complete Sprinkler Functional Configuration: Full-set front, rear and side spraying nozzles, 360° rotatable high-pressure water cannon, standard DN65 fire coupling and self-priming system, realizing full-scene watering and emergency fire fighting.
Premium Auxiliary Parts: Brand-name PTO, debris filter and hydraulic control valves, wear-resistant water hoses and top warning lights, reducing long-term failure rate.
Export Compliance Service: Support Euro II emission standard, provide full customs clearance documents and export certification, suitable for government bidding and bulk delivery to Africa, Central Asia and Middle East countries.
6. Operation and Maintenance Tips
Standard operation and daily maintenance can extend vehicle service life and guarantee stable spraying performance:
6.1 Daily Operation Specifications
6.2 Regular Maintenance Advice
Check water tank tightness, spraying nozzles and hydraulic pipelines before starting work to avoid water leakage
Test water cannon rotation and spraying modes in advance to ensure flexible mode switching
Prohibit pumping muddy water with excessive impurities to prevent filter and sprinkler pump clogging
Cut off PTO power firstly before stopping spraying to protect pump components
Drain residual water inside tank and pipelines after daily operation, especially for low-temperature regions
7. Frequently Asked Questions
Q1: Standard export name
Clean water filter and nozzle sediment every two weeks to keep smooth water output
Check water cannon rotating bearing and hydraulic valve sealing monthly, add lubricating oil regularly
Inspect water tank welding joints to avoid rust and water seepage
Maintain Weichai engine and Fast transmission following official SHACMAN maintenance handbook
Check top warning lights regularly to guarantee driving safety during night operation
A1: SHACMAN L3000 4×2 Sprinkler Truck, SHACMAN Multi-functional Water Spray Truck, LHD/RHD Municipal Water Tank Sanitation Truck.
Q2: Can this truck support left-hand and right-hand drive customization?
A2: Yes. This model supports both LHD and RHD customized production, fully adapting to road traffic rules of Southeast Asia, Africa, Central Asia and Middle East countries.
Q3: What is the maximum spraying range?
Q4: Does it support emergency fire rescue work?
A4: Absolutely. Equipped with DN65 standard fire coupling and high-pressure water cannon, it can connect fire hydrants rapidly and output high-pressure water for emergency fire rescue.
Q5: Is it suitable for overseas government bidding?
A5: Yes. Adopting mature SHACMAN heavy-duty chassis and standard export configuration, matched with Euro II emission standard and complete export documents, it owns stable performance and high cost performance, perfectly fitting overseas municipal bidding and bulk procurement.
Conclusion
SHACMAN L3000 4×2 Sprinkler Truck is a cost-effective, export-oriented multi-functional sanitation vehicle tailored for global environmental maintenance and municipal engineering demands. Integrated with water absorption, road flushing, dust suppression, greening irrigation and fire rescue functions, this vehicle adopts reliable SHACMAN L3000 heavy-duty chassis and matched famous-brand power assembly.
Equipped with full-set standard sprinkler accessories and adjustable high-pressure water cannon, it solves single function, narrow spraying range and poor road adaptability defects of traditional watering equipment. Supporting dual LHD and RHD customization, compatible with multiple national emission standards, this SHACMAN sanitation truck enjoys stable overseas after-sales service, becoming the preferred sanitation equipment for global municipal departments, engineering contractors and environmental protection enterprises.
