HOWO Sewer Vacuum Truck Export Professional Introduction
Table of Contents
1. Product Overview
2. Working Principle
3. Daily Application Scenarios
4. Comparison with Traditional Sanitation Vehicles
5. Buying Guide
6. Operation and Maintenance Tips
7. Frequently Asked Questions
Conclusion
1. Product Overview
Core Product Keywords: HOWO Sewer Vacuum Truck, Municipal Sanitation Vehicle, Sewage Treatment Vehicle, Wastewater Suction Truck, Sewer Dredging Equipment.
HOWO Sewer Vacuum Truck | Sanitation & Sewage Treatment Vehicle. As a key piece of municipal sanitation machinery, this sewer vacuum truck is equipped with premium vacuum assemblies. It specializes in sucking, hauling and emptying sewage, sludge and mixed waste. The airtight storage tank forms negative pressure to draw out waste from sewers, septic tanks and drainages. All collected materials will be conveyed to designated areas for treatment. Widely adopted in city cleaning, environmental projects and rural sewage management.
Body Structure
The tank adopts integrated stamping and welding process with thickened high-strength carbon steel. It features great tightness and pressure resistance, perfectly suited for vacuum work and hydraulic unloading.
Core Advantages
1. Efficient Performance: Fast suction and discharging speed guarantees high working productivity.
2. Wide Adaptability: Works well in various environments and handles different types of sewage and sludge waste.
3. Leak & Odor Proof: Fully sealed structure keeps the working environment clean without secondary pollution.
4. Practical & Economical: All-in-one design cuts down manual work and helps reduce operational expenditure.
2. Working Principle
The whole operating system of HOWO Sewer Vacuum Truck consists of three core parts: mature HOWO heavy-duty chassis power system, premium vacuum assembly and pressure-resistant fully sealed carbon steel tank.
After engine startup, the power take-off device transmits chassis power to drive the supporting vacuum assembly to run steadily. The premium vacuum device extracts internal air of the airtight storage tank, and generates stable negative pressure inside the tank body. Relying on atmospheric pressure difference, external sewage, sludge and solid-liquid mixed waste are automatically sucked into the tank from sewers, septic tanks and drainages.
Thanks to the integrated stamping welded tank with excellent tightness, it locks waste and foul smell inside the tank to avoid leakage. After waste collection, operators activate the hydraulic unloading system to discharge all pollutants thoroughly. The whole procedure realizes automatic suction, sealed transportation and hydraulic discharging, realizing integrated mechanized sanitation operation.
3. Daily Application Scenarios
Urban Municipal Sanitation: Daily sewer dredging, urban drainage pipeline blockage removal, public septic tank regular cleaning
Environmental Protection Projects: Polluted sewage collection, black and odorous water waste disposal, urban environmental renovation
Rural Sewage Management: Rural domestic sewage collection, village drainage ditch desilting, decentralized sewage disposal
Public Facilities Maintenance: Drainage pipeline maintenance, sewage pit cleaning for public parks and scenic spots
4. Comparison with Traditional Sanitation Vehicles
Vs Manual Sewage Cleaning: Traditional manual dredging depends on simple pumping tools and handwork, with slow working speed, huge labor input and serious odor leakage, which easily causes urban secondary pollution. This HOWO sewer vacuum truck realizes full mechanized operation, greatly saving labor cost and optimizing working environment.
Vs Ordinary Water Transport Trucks: Common water trucks only support simple liquid transportation, without negative pressure suction function. They cannot suck viscous sludge and mixed waste, while HOWO vacuum truck equips professional premium vacuum assemblies, applicable to diversified sewage disposal work.
Vs Non-standard Modified Sanitation Trucks: Irregular refitted vehicles adopt thin tank plates with simple welding craft, poor pressure resistance and tightness, easy to cause sewage leakage. This HOWO finished vehicle adopts thickened carbon steel with integral stamping welding, stable bearing capacity and reliable sealing performance, meeting international sanitation standards.
HOWO Sewer Vacuum Truck |
General | Chassis Brand | Sinotruk HOWO |
| Overall Dimension(L×W×H) | Approx 7000 × 2450 × 3000 mm |
| GVW / Kerb Weight | 9000kg / approx 5400kg |
| Drive Orientation | Left-hand Drive (LHD) |
Cab | Cab Type | High-roof Sleeper Cab (Row-and-a-half) |
| Cab Capacity | 3 seats (1 driver + 2 passengers) with rear sleeper berth |
| Air Conditioner | Standard equipped |
| Power Windows | Standard equipped |
| Central Lock | Standard equipped |
Engine | Fuel Type | Diesel |
| Engine Brand | Sinotruk |
| Rated Power | 116HP/85kW |
| Displacement | 3760cc |
| Emission Standard | Euro 2 (National 2) |
Chassis Parameter | Drive Type | 4X2 |
| Transmission | 6 forward +1 reverse |
| Wheelbase/No.of axle | 3360mm / 2 axles |
| Tyre Specification | 7.00R16 |
| Tyre Number | 6pcs + 1 spare tyre |
| Max Speed | 90km/h |
| Paint | Standard: white cab + customized superstructure color |
Superstructure | Tank Body Capacity | 5000Liters (customizable) |
| Tank Body Material | carbon steel, fully welded construction; 304 stainless steel optional |
| Vacuum Pump | High efficient,vacuum rate 93%, quick suction anddischarge ,suction lift 6 m |
| Inner baffles inside tank for prevention of longitidinal surge during moving. |
| The tank body does not have a lifting function, and there is a tank mouth onthe top of the tank body. The suspension rod with a suction pipe can beequipped with a DN100 suction pipe, and there is a DN150 sewage outlet onthe rear end. The internal anti-corrosion treatment of the tank body is carriedout, with a paint film thickness of no less than 100 microns. There is a 12meter long suction pipe (matched with a DN100 ball valve), and a 6 meter longsewage pipe (matched with a DN150 ball valve) |
5. Buying Guide
For overseas municipal sanitation departments, environmental engineering contractors and sanitation fleet purchasers, please check key configurations before procurement:
Genuine HOWO Heavy-duty Chassis: Mass-produced mature chassis with stable power output, low failure rate and global spare parts supply channels, reducing overseas after-sales maintenance risks.
Integrated Pressure-resistant Sewage Tank: Adopt thickened high-strength carbon steel via integral stamping and welding, outstanding pressure resistance and tightness, adapting to long-time negative pressure operation.
Original Premium Vacuum Assembly: Matching professional vacuum components to guarantee steady suction efficiency, suitable for long-time continuous sanitation operation.
Complete Export Certification: Factory original refitting, providing full set of customs clearance documents, supporting overseas government bidding and cross-border delivery.
6. Operation and Maintenance Tips
Standardized operation and routine maintenance can reduce vehicle failure rate and extend overall service life:
6.1 Daily Operation Specifications
Inspect tank airtightness, vacuum pipeline connection status before vehicle ignition
Check vacuum assembly operating status to avoid abnormal negative pressure during suction work
Do not suck oversized hard sundries to prevent pipeline blockage and vacuum component abrasion
Prohibit long-time overload suction operation to protect tank structure and vacuum parts
Clean tank interior and residual pipelines after daily work to prevent tank corrosion
6.2 Regular Maintenance Advice
Clean vacuum assemblies regularly to remove dirt and guarantee stable suction performance
Check tank welding seams quarterly, repair tiny cracks to prevent air leakage
Inspect hydraulic unloading system regularly to ensure smooth discharging
Follow official HOWO chassis maintenance manual for regular engine and chassis maintenance
7. Frequently Asked Questions
Q1: Official export name of this sanitation vehicle
A1: Standard export names: HOWO Sewer Vacuum Truck, HOWO Sewage Suction Vehicle, HOWO Municipal Sanitation Vacuum Truck.
Q2: What working conditions is this truck suitable for?
A2: It adapts to urban sewer dredging, septic tank cleaning, environmental treatment and rural sewage management, covering urban and rural sanitation scenarios.
Q3: What is the advantage of HOWO chassis?
A3: HOWO heavy-duty chassis enjoys mature manufacturing technology, reliable power performance and worldwide spare parts supply, with low daily maintenance cost, fit for overseas long-term sanitation operation.
Q4: Can this vehicle avoid sewage leakage and odor escape?
A4: Yes. The whole tank adopts fully sealed integral welding structure, with excellent leak-proof and odor-isolation effect, effectively reducing environmental secondary pollution.
Q5: Is the vehicle cost-effective for bulk procurement?
A5: Absolutely. It integrates suction, transportation and discharging functions, cutting extra equipment procurement cost. With low failure rate and economical maintenance expenditure, it is highly cost-effective for overseas bulk sanitation purchasing.
Conclusion
HOWO Sewer Vacuum Truck is a practical and cost-effective municipal sanitation equipment customized for global sewage disposal and sewer dredging demands. Equipped with premium vacuum assemblies and sturdy integrated carbon steel tank, it realizes automatic waste suction, sealed transportation and hydraulic unloading.
Combining high working efficiency, wide environmental adaptability, eco-friendly sealing performance and low operating cost, this vehicle solves low efficiency, serious pollution and high labor cost defects of traditional sanitation methods. With stable quality and complete export qualifications, it has become preferable sanitation equipment for municipal governments and environmental engineering contractors worldwide.
