SHACMAN X9 Single-axle Sewage Suction Truck Export Professional Introduction
Table of Contents
1. Product Overview
2. Working Principle
3. Daily Application Scenarios
4. Comparison with Traditional Sanitation Vehicles
5. Buying Guide
6. Operation and Maintenance Tips
7. Frequently Asked Questions
Conclusion
1. Product Overview
Core Product Keywords: SHACMAN X9 Sewage Suction Truck, Municipal Sanitation Vehicle, Sewer Dredging Truck, Wastewater Suction Equipment, Export Sanitation Truck.
The SHACMAN X9 single-axle sewage suction truck adopts the original SHACMAN X9 dedicated chassis with a 4×2 single-axle layout. It features strong power, stable load-bearing and flexible operation. Designed for urban sanitation, municipal pipeline maintenance, residential property cleaning, river and ditch treatment, and construction site sewage transportation, the vehicle integrates vacuum sewage suction, sewage transfer and hydraulic self-discharging functions. With high working efficiency and excellent durability, it is a mainstream model for urban and rural sanitation operations.
Equipped with a high-quality vacuum pump, the truck delivers powerful suction, long suction lift and fast pumping speed. It can efficiently suck sludge, sewage and sediment from sewers, septic tanks and sedimentation tanks. Fitted with an extended suction hose for a wider working range, the whole machine features low failure rate and easy maintenance.
Core Advantages
1. Various tank volumes from 5CBM to 20CBM are available, fitted with FAW, HOWO, Dongfeng and other mainstream domestic chassis. Customized stainless steel tank, high-pressure washing combined version and other optional configurations meet diverse demands from different countries.
2. Supported by mature production chain, we achieve large-scale mass production. Annual export quantity keeps growing, with regular bulk shipments to Southeast Asia, Africa, Middle East and Central Asia, stable delivery guaranteed for bulk orders.
3. Strong vacuum suction, automatic suction and discharge, hydraulic rear opening design; fully sealed tank prevents liquid leakage. Complete anti-overflow safety devices, sturdy body adapting to rough overseas road conditions, low breakdown rate and easy maintenance.
4. Cost-effective and reliable quality helps us occupy leading market proportion in sanitation equipment market of Africa, Southeast Asia and Middle East, widely chosen by municipal government and engineering clients with stable repeat orders.
2. Working Principle
The complete working system of SHACMAN X9 single-axle sewage suction truck includes three core modules: original SHACMAN X9 4×2 dedicated chassis power system, high-quality vacuum pump assembly and fully sealed sewage storage tank.
After engine ignition, the power take-off outputs chassis power to drive the matched high-quality vacuum pump to operate continuously. The vacuum pump discharges air inside the sealed tank to form stable negative pressure. Relying on atmospheric pressure difference, sludge, sewage and sediment inside sewers, septic tanks and sedimentation tanks are rapidly sucked into the tank through extended suction hose.
The whole tank adopts fully sealed structure to avoid sewage leakage and environmental pollution. Equipped with complete anti-overflow safety devices, it effectively prevents sewage backflow and protects vacuum components. After loading completion, operators activate the hydraulic system to open rear cover and finish automatic discharging. The integrated vacuum suction, transfer and hydraulic unloading design simplifies operation procedures and boosts overall working efficiency.
3. Daily Application Scenarios
Urban Sanitation Operation: Municipal sewer dredging, public drainage pipeline maintenance, downtown septic tank regular cleaning
Residential Property Management: Community sewage disposal, residential drainage desilting, domestic sediment cleaning for residential parks
Water Environment Renovation: Urban river and rural ditch sludge removal, watercourse sedimentation treatment
Construction Engineering: Construction site sewage transportation, foundation pit sludge suction, temporary construction sewage disposal
Cross-region Sanitation Projects: Adaptable for multi-country sanitation bidding projects, applicable to Southeast Asia, Africa and Middle East working conditions
4. Comparison with Traditional Sanitation Vehicles
Vs Manual Sewage Dredging: Traditional manual cleaning requires massive manpower, featuring low pumping speed and uncontrollable odor leakage, causing urban environmental pollution. SHACMAN X9 sewage suction truck realizes full mechanical automatic operation, cutting labor cost and eliminating secondary pollution.
Vs Fixed-type Sewage Suction Equipment: Stationary suction devices cannot move flexibly, limited by working sites and poor maneuverability. This mobile SHACMAN X9 truck owns flexible single-axle chassis, adaptable to scattered and complex outdoor working scenarios.
Vs Ordinary Refitted Sanitation Trucks: Common modified trucks have single configuration, fixed tank capacity and poor road adaptability. SHACMAN X9 model supports multi-chassis matching, 5-20CBM customizable tank volume and diversified customized functions, perfectly matching different national traffic and sanitation demands.
Shacman X9 Sewage Suction Truck ( 8000 liters) |
General | Chassis Brand | Shacman x9 |
| Overall Dimension | 5990 X 2200 X2570 mm |
| GVW / Kerb Weight | 8280kg / 3650 kg |
Cab | Cab Capacity | 2persons allowed |
| Air Conditioner | W/ air conditioner |
Engine | Fuel Type | Diesel |
| Engine Brand | YUNNEI Engine |
| Power | 150Hp (110 KW) |
| Displacement | 2499ml |
| Emission Standard | Euro 4 / Euro 5 |
Chassis | Drive Type | left or right hand drive |
| Transmission | WLY 6-speed gearbox with dedicated PTO |
| Wheelbase/No. of axle | 3300,3360 / 2 |
| Tyre Specification | 7.50R16LT14PR 8.25R16LT16PR |
| Tyre Number | 6 tyres and 1 spare tyre |
| Max Speed | 89 km/h |
| Paint | Metallic paint |
Superstructure | Tank Capacity | 8000 liters |
| Tank Material | Carbon steel |
| Standard Configuration ：Q235 high-quality carbon steel, thickness 5mm, inner wall anti-corrosion treatment;Flanged heads on both ends; tank with hydraulic tipping function, hydraulic opening & sealing rear cover |
Optional | Optional configurations：304 stainless steel tank with wear-resistant lining at tank bottom; stainless steel access ladder, top warning lamp and interlock alarm device. |
5. Buying Guide
For overseas municipal sanitation departments, environmental contractors and sanitation fleet purchasers, confirm core procurement indicators as follows:
Original SHACMAN X9 Chassis: Dedicated 4×2 single-axle chassis with strong power and flexible steering, suitable for rough overseas road conditions, stable bearing performance.
Customizable Tank Configuration: Optional tank capacity ranging from 5CBM to 20CBM, alternative mainstream brand chassis and stainless steel tank modification to fit local sanitation standards.
Reliable Vacuum & Safety System: High-efficiency original vacuum pump plus full-set anti-overflow safety accessories, leak-proof tank structure to guarantee long-term continuous operation.
Stable Export Supply Capacity: Mature mass production chain, stable bulk delivery capacity, rich export experience for Africa, Middle East and Southeast Asia, complete customs clearance documents provided.
6. Operation and Maintenance Tips
Standardized operation and regular maintenance can lower failure rate and extend vehicle service life, adapting to long-term overseas high-intensity work:
6.1 Daily Operation Specifications
6.2 Regular Maintenance Advice
Check tank tightness, vacuum pump running status and anti-overflow device sensitivity before startup
Inspect extended suction hose integrity to avoid air leakage affecting suction efficiency
Avoid sucking massive hard gravel and sundries to prevent vacuum pump abrasion and pipeline clogging
Operate hydraulic rear opening device only after vehicle parking to prevent hydraulic malfunction
Clean tank interior and suction pipeline after daily operation to reduce corrosive sediment accumulation
7. Frequently Asked Questions
Q1: Official export name
Clean vacuum pump and internal pipeline every month to guarantee stable suction power
Check tank sealing parts and hydraulic components regularly, replace aging accessories timely
Calibrate anti-overflow safety devices quarterly to avoid backflow risks
Abide by official SHACMAN chassis maintenance guidelines to maintain power performance
A1: Standard export names: SHACMAN X9 Single-axle Sewage Suction Truck, SHACMAN X9 Sanitation Vacuum Truck, Municipal Sludge Suction Transport Vehicle.
Q2: What customized services can be provided?
A2: We support adjustable tank volume from 5CBM to 20CBM, optional FAW, HOWO, Dongfeng and SHACMAN original chassis, customized stainless steel tank and high-pressure washing integrated version.
Q3: Which overseas markets are the main export destinations?
A3: We have long-term bulk export business to Southeast Asia, Africa, Middle East and Central Asia, with matched local road adaption modification and after-sales support.
Q4: Can the truck adapt to poor road conditions?
A4: Yes. Adopting dedicated SHACMAN X9 chassis and reinforced vehicle body, it owns strong load-bearing capacity and shock resistance, fully adaptable to rough roads in Africa and Central Asia.
Q5: What are the core competitiveness of this model?
A5: Diversified customizable configurations, mature mass production and stable delivery, sturdy road adaptability and low maintenance cost. With verified overseas market reputation, it boasts high cost performance for government sanitation procurement and engineering projects.
Conclusion
SHACMAN X9 single-axle sewage suction truck is a highly adaptable and export-oriented sanitation vehicle tailored for global municipal sewage disposal demands. Built on original dedicated SHACMAN X9 4×2 chassis, it integrates vacuum suction, sewage transfer and hydraulic self-discharging functions, equipped with high-efficiency vacuum pump for stable suction performance.
Benefiting from multi-dimensional customizable configurations, mature industrial supply chain and verified overseas road adaptability, this model solves single-function, poor adaptability and unstable delivery defects of traditional sanitation vehicles. With reliable quality, low operation cost and global market recognition, it is the preferred sanitation equipment for municipal sanitation departments and environmental engineering contractors across Southeast Asia, Africa and Middle East countries.
